5th Axis PS20F | RockLock 96 mm Single Pull Stud - Steel - 125.73 mm x 125.73 mm x 30.48 mm

Description

The 5th Axis PS20F RockLock 96 mm pull stud is a precision fixturing plate made for modular workholding systems. This RockLock single-pull stud 125.73 x 125.73 x 30.48 mm plate mounts directly to 96 mm RockLock bases for fast, repeatable locations. Manufactured from hardened steel, the RockLock PS20F pull stud offers high strength and durability under heavy clamping loads. Designed as a precision pull stud for CNC machining setup, the plate minimizes runout and maintains concentricity in demanding operations. The 5th Axis PS20F RockLock 96 mm pull stud supports vacuum workholding systems when used with compatible adapters and seals. Its 125.73 × 125.73 × 30.48 mm size gives a stable footprint for small-to-medium parts while preserving access for tooling. As a steel RockLock PS20F pull stud for fixturing, it resists deformation and holds tight tolerances during repetitive cycles. The plate’s geometry simplifies pallet changeover and speeds setup in high-mix production environments. Precision machining of the mating faces ensures accurate registration to the RockLock base and predictable clamping forces. Use the 5th Axis PS20F pull stud with modular fixturing plates to build scalable workholding stacks for multi-axis machining. This RockLock pull stud for vacuum workholding systems pairs well with vacuum pallets and dedicated vacuum ports for composite or thin parts. The hardened steel construction and controlled heat treatment enhance fatigue life for long-term shop use. Installation is straightforward and secure, enabling rapid fixture swaps and reduced non-cutting time. Engineers specify the 5th Axis PS20F when they require a compact, precision pull stud for repeatable CNC setup and robust fixturing. Overall, the 5th Axis PS20F RockLock 96 mm pull stud delivers reliable clamping performance and precision alignment in modular fixturing systems.

Product Features and Benefits

Designed For 96 mm RockLock Bases

The 5th Axis PS20F interfaces directly with 96 mm RockLock bases to provide quick, repeatable mounting for modular fixturing.

Hardened Steel Construction

Steel construction with controlled hardening improves wear resistance and ensures the RockLock single pull stud keeps precise dimensions under load.

Compact, Stable Footprint

The 125.73 × 125.73 × 30.48 mm size offers a rigid platform for small and medium parts while maintaining tool access around the plate.

Precision-Machined Mating Faces

Ground and bored reference surfaces reduce runout and simplify indexing when used as a precision pull stud for CNC machining setups.

Vacuum Workholding Compatibility

Can be integrated into vacuum workholding systems or combined with RockLock adapters for mixed-method clamping solutions.

Frequently Asked Questions

What are the overall dimensions of the 5th Axis PS20F pull stud?

The RockLock single pull stud plate measures 125.73 x 125.73 x 30.48 mm.

What material is the 5th Axis PS20F made from?

The plate is manufactured from hardened steel for durability in repetitive fixturing operations.

Does this pull stud work with 96 mm RockLock bases?

Yes, the 5th Axis PS20F is specifically made to mount to 96 mm Rock Lock bases for secure workholding.

Can the PS20F be used in vacuum workholding systems?

It is compatible with vacuum workholding solutions when paired with appropriate seals and vacuum adapters.

Is the RockLock pull stud suitable for precision CNC setups?

Yes, precision machining of mating faces and hardened steel construction make it ideal for precision pull studs for CNC machining setups.
