The replaceable head model allows for on-machine replacement, significantly reducing set-up and down time and allowing for multiple diameters within the same arbor reducing inventory requirements.
Features:
- A variety of leads provide tailored solutions for every applications
- Tight tolerances (+/- 0.0002") capable with expandable diameter head design
Product Specifications
| # MFG | 7001-MC-002 |
| Assembled Reference Length (mm) | 113mm |
| Length of Cut (mm) | 65mm |
| Maximum Diameter (Decimal Inch) | 0.6932" |
| Maximum Diameter (mm) | 17.609mm |
| Minimum Diameter (Decimal Inch) | 0.5752" |
| Minimum Diameter (mm) | 14.61mm |
| Shank Diameter (mm) | 16.00mm |
| Series | 7001 |
| Shank Type | Cylindrical |
| Length Type | Short |
| Coolant | Central Coolant |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Allied Machine and Engineering
Maximum Diameter (Decimal Inch):
0.6932"
Maximum Diameter (mm):
17.61mm
Minimum Diameter (Decimal Inch):
0.5752"
Minimum Diameter (mm):
14.61mm
Shank Diameter (mm):
16.00mm
Length of Cut (mm):
65.00mm
Shank Type:
Cylindrical
