Introducing our CCT-7 Tool Coating a propriety CVD (Chemical Vapor Deposition) coating. The Chemical Vapor Deposition (CVD) coating process is the application of a thin, solid coating onto the tool through a vaporous chemical reaction. In this process, the tool is exposed to a mixture of gases at high temperatures in a controlled vacuum chamber. These gases react on the tool’s surface, forming a thin, uniform coating.
Product Specifications
| Manufacturer Part Number | 62006 |
| Diameter (Inch) | 1/4" |
| Length of Cut (Inch) | 1" |
| Overall Length (Inch) | 4" |
| Number of Flute | 4 |
| Coating | CCT-7 (CVD) |
| End Type | Square |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Colton Industrial Tools
Mill Diameter (Inch):
1/4"
Mill Diameter (Decimal Inch):
0.2500"
Mill Diameter (mm):
6.35mm
Length of Cut (Inch):
1"
Length of Cut (Decimal Inch):
1.0000"
Length of Cut (mm):
25.40mm
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000
Overall Length (mm):
101.60mm
Finish/Coating:
CCT-7 (CVD)
Number of Flutes:
4
