Suitable for 5-axis machining of complex components, S791 milling cutters from Dormer have a barrel form. The large tangential radius provides greater contact, reducing the number of passes by up to 50%, whilst the nose radius provides greater accuracy and can also be used as a general ball nose cutter. S791 barrel form machine utters have positive geometry for a smooth cutting action to reduce the possibility of work hardening, and an aluminium chromium nitride coating to reduce friction and provide excellent wear resistance, leading to increased tool life.
| Max Depth of Cut (mm) | 26mm |
| Connection Diameter (Inch) | 0.3937" |
| Cutting Diameter (Inch) | 0.3937" |
| Overall Length (Inch) | 2.9528" |
| Material Code | HM |
| Radial Rake Angle | 8 |
| No of Flute | 4 |
| Flute Helix Angle | 30 |
| Corner Radius (mm) | 2mm |
| Coating | AlCrN |
| Surface Color | Black-Deep Purple |
| Country of origin | Malaysia |
