Features:
- Hard milling for materials up to 66 HRC
- External
Product Specifications
| End Style | Ball Nose |
| End Type | Finisher |
| Size | 12 mm |
| Applicable Material | High Tensile Strength Materials, Hardened Steels |
| Type | Ball Nose |
| Length Group | Extra Length |
| Features: | Tight tolerance high performance milling. Very stable milling properties |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 2 |
| Helix Angle (Degrees) | 30 Degree |
| Shank Diameter (mm) | 12 mm |
| Shank Tolerance | h5 |
| Shank Style | HA |
| Overall Length (mm) | 100 mm |
| Flute Length (mm) | 16 mm |
| Flute Direction | Right Hand |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Finish/Coating:
TIALN
Helix Angle:
30 Degree
Flute Direction:
Right Hand
Application:
Finisher
