Features:
- Hard milling for materials up to 66 HRC
- External
Product Specifications
| End Style | Corner Chamfer |
| End Type | Finisher |
| Size | 10 mm |
| Applicable Material | High Tensile Strength Materials, Hardened Steels |
| Type | Square End |
| Length Group | Stub Length |
| Features: | Tight tolerance high performance milling. Very stable milling properties |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 6 |
| Helix Angle (Degrees) | 50 Degree |
| Shank Diameter (mm) | 10 mm |
| Shank Tolerance | h5 |
| Shank Style | HB |
| Overall Length (mm) | 66 mm |
| Flute Length (mm) | 14 mm |
| Flute Direction | Right Hand |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Mill Diameter (mm):
10mm
Number of Flutes:
6
Length of Cut (Inch):
14mm
Length of Cut (mm):
14mm
Material:
Carbide
Finish/Coating:
TIALN
Shank Diameter (Inch):
10mm
Shank Diameter (mm):
10mm
Application:
Finisher
Overall Length (Inch):
66mm
Overall Length (mm):
66mm
Helix Angle:
50Ëš
Flute Direction:
RH
