Features:
- Multi-functional tool. Wear resistant sub-micro grain carbide
- External
Product Specifications
| End Style | Corner Chamfer |
| End Type | Finisher |
| Size | 12 mm |
| Applicable Material | Universal Materials |
| Type | Square End |
| Length Group | Extra Length |
| Features: | High performance design for universal applications |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 5 |
| Helix Angle (Degrees) | 38/42 Degree |
| Shank Diameter (mm) | 12 mm |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (mm) | 107 mm |
| Flute Length (mm) | 48 mm |
| Flute Direction | Right Hand |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Mill Diameter (mm):
12mm
Number of Flutes:
5
Length of Cut (mm):
48mm
Material:
Carbide
Finish/Coating:
TIALN
Shank Diameter (mm):
12mm
Application:
Finisher
Overall Length (mm):
107mm
Helix Angle:
38/42 Degree
Flute Direction:
RH
interval quantity:
1
