Features:
- Higher tool life and performance. Internal coolant hole for maximum chip evacuation in difficult materials
- Axial
Product Specifications
| End Style | Corner Radius |
| End Type | Rougher |
| Size | 12 mm |
| Applicable Material | Stainless Steel, Titanium, Nickel Alloys |
| Type | Corner Radius |
| Length Group | Extra Length |
| Features: | High performance geometry for aerospace materials. Semi-finishing fine tooth roughing profile Coolant Fed design |
| Coating | TIN/TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 45 Degree |
| Shank Diameter (mm) | 12 mm |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (mm) | 93 mm |
| Flute Length (mm) | 26 mm |
| Flute Direction | Right Hand |
| Corner Radius | 2.5 mm |
| Application | Rough/Finish |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Decimal Inch):
0.4724"
Cutting Diameter (mm):
12.00mm
Shank Diameter (mm):
12.00mm
Corner Radius (mm):
2.50mm
Cutting Edge Material:
Carbide
Flute Length (mm):
26.00mm
Number of Flutes:
4
Flute Direction:
Right Hand
Finish/Coating:
TiN/TiAlN
Tool Type:
Corner Radius
Application:
Rough / Finish
Overall Length (mm):
93.00mm
interval quantity:
1
