Features:
- Designed for high performance milling in tougher materials
- External
Product Specifications
| Decimal Size (Inch) | 1.0" |
| End Style | Corner Radius |
| End Type | Finisher |
| Size | 1" |
| Applicable Material | Steel, Cast Iron, Hardened Materials |
| Type | Corner Radius |
| Length Group | Standard |
| Features: | Modified flute form and variable spacing for high performance milling |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 50 Degree |
| Shank Diameter (Inch) | 1" |
| Shank Tolerance | h5 |
| Shank Style | HB |
| Overall Length (Inch) | 4" |
| Flute Length (Inch) | 1-1/2" |
| Flute Direction | Right Hand |
| Corner Radius | 0.05" |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Inch):
1"
Cutting Diameter (Decimal Inch):
1.0000"
Shank Diameter (Inch):
1"
Shank Diameter (Decimal Inch):
1.0000"
Corner Radius (Decimal Inch):
0.0500"
Cutting Edge Material:
Carbide
Flute Length (Inch):
1-1/2"
Number of Flutes:
4
Flute Direction:
Right Hand
Finish/Coating:
TiAlN
Tool Type:
Corner Radius
Application:
Finishing
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
interval quantity:
1
