Emuge 2998L.018020 | 3/16" Diameter x 0.020" Corner Radius 2" OAL 4 Flute ALCR Coated Corner Radius End Mill

$21.28
Brand:
Emuge
Mill Diameter (Inch):
3/16"
Mill Diameter (Decimal Inch):
0.1875"
Mill Diameter (mm):
4.76mm
Number of Flutes:
4
Corner Radius (Decimal Inch):
0.0200"
Corner Radius (mm):
0.51mm
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Finish/Coating:
ALCR
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Shank Diameter (mm):
4.76mm
Application:
Finishing
interval quantity:
1
SKU:
25235584
Weight:
1.23 LBS
Shipping:
Calculated at Checkout
Emuge 2998L.018020 | 3/16" Diameter x 0.020" Corner Radius 2" OAL 4 Flute ALCR Coated Corner Radius End Mill

Features:

  • TOP-Cut VAR carbide end mill 4 flute design for roughing and finishing in almost all materials
  • Special tool geometry enable low-vibration machining and universal use in almost all materials and milling processes
  • Wear resistant sub-micro grain carbide substrate
  • ALCR coating for longer tool life and very good suitability for high-alloyed materials

Product Specifications
Manufacturer Part Number2998L.018020
Cutting Diameter (Inch)3/16"
Cutting Diameter (Decimal Inch)0.188"
Corner Radius (Decimal Inch)0.020"
Overall Length (Inch)2"
Flute-Length (Inch)7-16"
Shank Toleranceh5
Tool Cylindrical - Shank StyleCylindrical - HA
Shank StandardDIN 6535
Flute DirectionRight Hand
Group LengthStandard Length
Coolant Supply PropertyExternal
Coolant FedNo
Number of Flute4
Flute Helix Angle (Degree)35-38 Degree
Cutting Edge MaterialCarbide
CoatingALCR
Tool TypeCorner Radius
End Mill - End StyleSquare & Corner Radius End Mills
End ShapeCorner Radius
ApplicationFinishing
Product TypeCorner Radius End Mill
