Features:
- High performance design for universal applications
- Provides maximum chip removal rates in a wide range of materials
Product Specifications
| Chamfer Form | |
| Size | 1" |
| Applicable Material | Universal Materials |
| Application | Finisher |
| Type | Corner Radius |
| Length Group | Standard |
| Coolant Fed | External |
| Coating/Finish | ALCR |
| Material | Carbide |
| Number of Flutes | 5 |
| Helix Angle (Degrees) | 35/38 Degree |
| Shank Diameter (mm) | 1" |
| Shank Tolerance | h6 |
| Shank Style | HA |
| Overall Length (mm) | 4" |
| Flute Length (mm) | 1-1/2" |
| Flute Direction | Right Hand |
| Corner Radius | 0.06 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Inch):
1"
Cutting Diameter (Decimal Inch):
1.0000"
Shank Diameter (Inch):
1"
Shank Diameter (Decimal nch):
1.0000"
Cutting Edge Material:
Carbide
Flute Length (Inch):
1-1/2"
Number of Flutes:
5
Flute Direction:
Right Hand
Finish/Coating:
ALCR
Tool Type:
Corner Radius
Application:
Finishing
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
interval quantity:
1
