Product Specifications
Chamfer | 4 -5 P |
Chamfer Form | B |
Pitch | 2 |
Size | M 14 |
Thread Limit | 6H |
Thread Standard | M |
Application | Through Hole |
Coolant Fed | No |
Coating | TIN |
Material | HSSE |
Flutes | 3 |
Helix Angle (Degrees) | 0 Degree |
Shank Diameter (mm) | 0.429" |
Dimension Standards | ANSI/ANSI |
Shank Tolerance | h9 |
Overall Length (mm) | 3.59" |
Thread Length (mm) | 1.024" |
Flute Direction | Right Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Ships:
From Manufacturer
Brand:
Emuge
Thread Size:
M14 X 2
Thread Limit:
6H
Number of Flutes:
3
Thread Standard:
M
Chamfer:
4 -5 P
Finish/Coating:
No
Material:
HSSE
