Product Specifications
| Chamfer | 1.5-2 P |
| Chamfer Form | E |
| Pitch | 0.8 |
| Size | M 5 |
| Thread Limit | 6HX |
| Thread Standard | M |
| Coolant Fed | Axial |
| Coating/Finish | TICN |
| Material | Carbide |
| Shank Diameter (mm) | 6 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 70 mm |
| Flute Direction | Right Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Shank Diameter (mm):
6.00mm
Cutting Edge Material:
Carbide
Thread Size:
M 5 x 0.8
Thread Standard:
M
Flute Direction:
Right Hand
Finish/Coating:
TiCN
Tool Type:
Rekord D-GAL/E
Application:
Spiral Flute Taps
Overall Length (mm):
70.00mm
interval quantity:
1
