Emuge BU20S810.5637 | STI #10-32 UNF -Tap -Rekord B -Al

$66.48
Ships:
From Manufacturer
Ships:
From Manufacturer
Brand:
Emuge
Thread Size:
10-32
Thread Limit:
3B
Number of Flutes:
2
Chamfer:
4 -5 P
Material:
HSSE
Finish/Coating:
GLT-8
Overall Length (Inch):
3-5/32"
Overall Length (Decimal Inch):
3.1500"
Overall Length (mm):
80.01mm
Thread Standard:
STI-UNF
Thread Length (Inch):
19/32"
Thread Length (Decimal Inch):
0.5910"
Thread Length (mm):
15.02mm
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2550"
Shank Diameter (mm):
6.48mm
SKU:
15038443
Weight:
0.04 LBS
Shipping:
Calculated at Checkout
BU20S810.5637-B

Features:

  • Rekord B-AL tap is designed for wrought aluminum materials
  • Longer tool life and more consistent thread quality
