Product Specifications
| Chamfer | 4-5 P |
| Chamfer Form | B |
| Pitch | 2.5 |
| Size | M 20 |
| Thread Limit | 6HX |
| Thread Standard | M |
| Coolant Fed | Radial |
| Coating/Finish | GLT-1 |
| Material | HSSE-PM |
| Shank Diameter (mm) | 16 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 140 mm |
| Flute Direction | Straight |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Ships:
From Manufacturer
