Features:
- Softsynchro collet holder with patented length compensation feature
- Increases tool life and thread quality
Product Specifications
| Size | #8-3/4" (M4-M20) |
| Application | Tapping Tool Holder |
| Type | Tension / Compression |
| Shank Diameter (mm) | HSK-A80 |
| Coolant Fed | Axial |
| Shank Tolerance | DIN 69893 A |
| Shank Style | HSK |
| Projection Length (mm) | 113.3 mm |
| Nose Diameter (mm) | 50 mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Projection (Inch):
4-29/64"
Projection (mm):
113.3mm
Projection (Decimal Inch):
4.4600"
Nose Diameter (Decimal Inch):
1.9700"
