Features:
- For economical production of internal pipe threads in a wide range of materials
- Optimized cutting geometry that works well in a job shop enviroment with multiple materials
Product Specifications
| EDP Number | GFT9B836.9678 |
| Pitch (Inch) | 14" |
| Size | 1/2 - 3/4 |
| Applicable Material | Universal Materials |
| Application | Full Profile |
| Type | Multi-Thread Mill |
| Coating | TICN |
| Material | Carbide |
| Flutes | 4 |
| Flute / Helix Angle | 15 Degree |
| Shank (Inch) | 5/8" |
| Shank Tolerance | h6 |
| Shank Style | HA |
| Overall Length (Inch) | 3-1/2" |
| Flute Length (Inch) | 1.034" |
| Flute Direction | Left Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Decimal Inch):
0.2320"
Shank Diameter (Inch):
5/8"
Cutting Edge Material:
Carbide
Thread Length (Decimal Inch):
1.0340"
Flute Length (Decimal Inch):
1.0340"
Thread Size:
1/2 - 3/4-14
Thread Standard:
NPT
Threads per Inch (TPI):
14 TPI
Number of Flutes:
4
Flute Direction:
Left Hand
Finish/Coating:
TiCN
Tool Type:
MULTI-THREAD MILL
Application:
Thread Milling
Overall Length (Inch):
3-1/2"
