Features:
- High penetration rate carbide drill with double margin flute design Unique web construction Sub-micro grain carbide
- Creates short consistent chip forms which enables higher penetration rates and accurate hole location
Product Specifications
Manufacturer Part Number | TA229744.0300 |
Cutting Diameter (Decimal Inch) | 0.118" |
Cutting Diameter (mm) | 3.00mm |
Overall Length (mm) | 78.00mm |
Flute Length (mm) | 38.00mm |
Shank Tolerance | h6 |
Tool Cylindrical - Shank Style | HA |
Shank Standard | DIN 6535 |
Flute Direction | Right Hand |
Group Length | 8xD |
Coolant Supply Property | Internal |
Coolant Fed | Yes |
Number of Flute | 2 |
Point Angle (Degree) | 135 Degree |
Flute Helix Angle (Degree) | 30 Degree |
Cutting Edge Material | Carbide |
Coating | TiAlN-T63 |
Tool Type | MULTI-DRILL |
Application | High Penetration Rate Drill |
Product Type | Extra Long Drill Bit |

Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Finish/Coating:
TiAlN-T63
Overall Length (Inch):
3-5/64"
Overall Length (Decimal Inch):
3.0709"
Overall Length (mm):
78.00mm
Flute Length (Inch):
1-1/2"
Flute Length (Decimal Inch):
1.4961"
Flute Length (mm):
38.00mm
Drill Point Angle:
135 Degree
