Features
- DIN coolant through the flange
- All ground body
- CAT40 Premium balanced to 20,000 RPM
- CAT50 Premium balanced to 15,000 RPM
Product Specifications
| Manufacturer Part Number | 531270 |
| Collet System | Double Angle |
| Collet Series | DA100 |
| Shank Type | Taper Shank |
| Taper Size | CAT40 |
| Projection (Decimal Inch) | 3.5" |
| Minimum Collet Capacity (Inch) | 3/64" |
| Maximum Collet Capacity (Inch) | 9/16" |
| Balanced to (RPM) | 20000 RPM |
| Collet Nut Diameter (Decimal Inch) | 1.06" |
| Seat Depth (Decimal Inch) | 1.15" |
| Product Type | Collet Chuck |
