Features
- DIN Coolant option-standard
- All ground body
- Factory balanced to save spindle life, tool life and increased productivity
- Premium balanced to G2.5 @ 30,000 RPM
- Threaded through holes for a back-up screw (tool stop) or coolant through when removed
Product Specifications
| Manufacturer Part Number | 531438 |
| Collet System | ER |
| Collet Series | ER20 |
| Shank Type | Taper Shank |
| Taper Size | CAT50 |
| Projection (Decimal Inch) | 2.5" |
| Minimum Collet Capacity (Decimal Inch) | 0.039" |
| Maximum Collet Capacity (Decimal Inch) | 0.511" |
| Balanced to (RPM) | 25000 RPM |
| Collet Nut Diameter (Decimal Inch) | 1.38" |
| Seat Depth (Decimal Inch) | 1.06" |
| Tightening Torque (Nm) | 81.3 |
| Product Type | Collet Chuck |
