Features
- High rigidity and torque transmission (almost double the rigidity of V-flange holders)
- Extreme concentricity enhance tool life performance
- Coolant through capabilities
Product Specifications
| Manufacturer Part Number | 536160 |
| Taper Size | HSK63A |
| Shank Type | Taper Shank |
| Hole Diameter (Decimal Inch) | 1" |
| Nose Diameter (Decimal Inch) | 2.362" |
| Projection (Decimal Inch) | 5.118" |
| Collet Range (Inch) | 0.125-1.000" |
| Collet Series (Inch) | GS 1" |
| Seat Depth (Decimal Inch) | 3.15" |
| Tightening Torque (Nm) | 50-70 |
| Product Type | Milling Chuck |
