Features
- High rigidity and torque transmission (almost double the rigidity of V-flange holders)
- Extreme concentricity enhance tool life performance
- Coolant through capabilities
Product Specifications
| Manufacturer Part Number | 536170 |
| Taper Size | HSK100A |
| Shank Type | Taper Shank |
| Hole Diameter (Decimal Inch) | 0.75" |
| Nose Diameter (Decimal Inch) | 2.047" |
| Projection (Decimal Inch) | 5.315" |
| Collet Range (Inch) | 0.125-0.750" |
| Collet Series (Inch) | GS 3/4" |
| Seat Depth (Decimal Inch) | 3.15" |
| Tightening Torque (Nm) | 50-70 |
| Product Type | Milling Chuck |
