Features
- High rigidity and torque transmission (almost double the rigidity of V-flange holders)
- Extreme concentricity enhance tool life performance
- Coolant through capabilities
Product Specifications
| Manufacturer Part Number | 536182 |
| Taper Size | HSK100A |
| Shank Type | Taper Shank |
| Hole Diameter (Decimal Inch) | 2" |
| Nose Diameter (Decimal Inch) | 4.134" |
| Projection (Decimal Inch) | 4.921" |
| Collet Range (Inch) | 1.000-2.000" |
| Collet Series | GS 2 |
| Seat Depth (Decimal Inch) | 3.543" |
| Tightening Torque (Nm) | 150-170 |
| Product Type | Milling Chuck |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
