Harvey Tool 16919 | 0.1700" Diameter x 0.3660" LOC x 0.1875" (3/16) Shank x 3 Flute Uncoated Carbide Multi-Form Thread Milling Cutter

$168.40
Brand:
Harvey Tool
Cutter Diameter (Decimal Inch):
0.1700"
Length of Cut (Decimal Inch):
0.3660"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Included Angle:
60 Degree
Number of Flutes:
3
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Shank Diameter (mm):
4.76mm
Finish/Coating:
Uncoated
interval quantity:
1
SKU:
25211127
UPC:
Weight:
0.05 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Thread Milling Cutters - Multi-Form - Metric feature Harvey Tools that are intended to cut internal and external

  • Able to cut larger threads of the same pitch
  • Mills Right Hand and Left Hand Threads
  • CNC ground in the USA
  • Fractional Shanks
  • Helical Flutes
  • Solid Carbide

Product Specifications
Tool Number16919
Cutter Diameter (Inch)0.1700"
Length of Cut (Inch)0.3660"
Overall Length (Inch)2.5000" (2-1/2)
Included Angle60
Flutes3
SizeM6-0.75
Shank Diameter (Inch)0.1875" (3/16)
CoatingUncoated

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Harvey Tool
Cutter Diameter (Decimal Inch):
0.1700"
Length of Cut (Decimal Inch):
0.3660"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Included Angle:
60 Degree
Number of Flutes:
3
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Shank Diameter (mm):
4.76mm
Finish/Coating:
Uncoated
interval quantity:
1
