Product Specifications
| Length of Cut (Decimal Inch) | 0.2940" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Angle per Side | 15 Degree |
| Included Angle | 30 Degree |
| Number of Flutes | 1 |
| Flat on Part (Decimal Inch) | 0.0300" |
| Type | II |
| Split Length (Decimal Inch) | 0.0938" |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | Uncoated |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Length of Cut (Decimal Inch):
0.2940"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Finish/Coating:
Uncoated
Material:
Carbide
Included Angle:
30 Degree
Ships:
From Partner Facility
