Product Specifications
| Mill Diameter (Decimal Inch) | 0.1180" |
| Number of Flutes | 3 |
| Finish/Coating | AlTiN |
| Length Of Cut (Decimal Inch) | 0.1770" |
| Overall Reach (Decimal Inch) | 1.4200" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.0000" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Center Cutting (Yes/No) | Yes |
| Neck Diameter (Decimal Inch) | 0.1165" |
| LOC Multiple | 1.5x |
| Reach Multiple | 12x |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Decimal Inch):
0.1180"
Number of Flutes:
3
Material:
Carbide
Finish/Coating:
AlTiN
Length of Cut (Decimal Inch):
0.1770"
Shank Type:
Reduced
Overall Reach (Decimal Inch):
1.4200"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Single or Double End:
Single
Center Cutting:
Yes
Cutting Direction:
Right
Ships:
From Partner Facility
