Product Specifications
| Cutter Diameter (Inch) | 1/32" |
| Cutter Diameter (Decimal Inch) | 0.0310" |
| Neck Diameter (Decimal Inch) | 0.0160" |
| Cutter Width (Inch) | 1/64" |
| Cutter Width (Decimal Inch) | 0.0150" |
| Neck Length (Inch) | 3/32" |
| Neck Length (Decimal Inch) | 0.0930" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.5000" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 2 |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Included Angle:
90 Degree
Cutting Diameter (Inch):
1/32"
Cutting Diameter (Decimal Inch):
0.0310"
Cutting Width (Inch):
1/64"
Cutting Width (Decimal Inch):
0.0150"
Material:
Carbide
Finish/Coating:
AlTiN
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Ships:
From Partner Facility
