Designed to mill hardened tool, die, and mold steels up to 55Rc
- Designed to mill hardened tool, die, and mold steels up to 55Rc
- Increased shank diameter to maintain strength and stiffness
- h6 shank tolerance for high precision tool holders
- Stub flute for maximum rigidity
- CNC ground in the USA
- Center cutting
- Solid carbide
Product Specifications
| Tool Number | 786278-C6 |
| Cutter Diameter (Inch) | 0.0780" (5/64) |
| Neck Diameter (Inch) | 0.0765" |
| Length of Cut (Inch) | 0.1170" |
| Overall Reach (Inch) | 0.4060" (13/32) |
| Overall Length (Inch) | 2.5000" (2-1/2) |
| Flutes | 6 |
| LOC Multiple | 1.5x |
| Reach Multiple | 5x |
| Shank Diameter (Inch) | 0.2500" (1/4) |
| Coating | C6 |
