Product Specifications
| Length of Cut (Decimal Inch) | 0.1200" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 1 |
| Flat on Part (Decimal Inch) | 0.0100" |
| Type | II |
| Split Length (Inch) | 1/8" |
| Split Length (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Length of Cut (Decimal Inch):
0.1200"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Finish/Coating:
AlTiN
Material:
Carbide
Included Angle:
90 Degree
Ships:
From Partner Facility
