Product Specifications
| Manufacturer Part Number | 816078 |
| Drill Diameter (Decimal Inch) | 0.078" |
| Drill Diameter (Inch) | 5/64" |
| Flute Length (Decimal Inch) | 0.117" |
| Overall Length (Decimal Inch) | 1.500" |
| Overall Length (Inch) | 1-1/2" |
| Angle per Side (Degree) | 45 Degree |
| Included Angle (Degree) | 90 Degree |
| Number of Flute | 2 |
| LOC Multiple | (1.5x) |
| Web Thickness (Decimal Inch) | 0.005" |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.125" |
| Shank Diameter (Inch) | 1/8" |
| Metric | No |
| Coating | Uncoated |
| Product Type | Spotting Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Finish/Coating:
Uncoated
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.10mm
Interval quantity:
1
