Product Specifications
| Neck Diameter (Decimal Inch) | 0.0250" |
| Length of Cut (Decimal Inch) | 0.0130" |
| Overall Reach (Inch) | 1/8" |
| Overall Reach (Decimal Inch) | 0.1250" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Tip (Decimal Inch) | 0.0030" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 2 |
| Reach Multiple | 5x |
| Type | I |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutter Head Diameter (Decimal Inch):
0.0030"
Included Angle:
90 Degree
Number of Flutes:
2
Material:
Carbide
Overall Part Length (Inch):
2-1/2"
Overall Part Length (Decimal Inch):
2.500"
Finish/Coating:
AlTiN
Ships:
From Partner Facility
IsDiscontinued:
