Features
- Optimized for hardened steels 45-68 Rc
- Increased flute count for added strength and tool life
- Latest generation AlTiN Nano coating offers superior hardness and heat resistance
- 270 Degree spherical ball
- Designed for undercutting, deburring, and multi-axis machining
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 823310-C6 |
| Cutter Diameter (Inch) | 0.1562" (5/32) |
| Neck Diameter (Inch) | 0.0980" |
| Neck Diameter (mm) | 2.5mm |
| Length of Cut (Inch) | 0.1330" |
| Overall Reach (Inch) | 0.3830" |
| Overall Length (Inch) | 2.0000" (2) |
| Neck Length (Inch) | 0.2500" (1/4) |
| Radius (Inch) | 0.0781" (5/64) |
| Shank Diameter (Inch) | 0.1875" (3/16) |
| Wrap Angle | 270 Degree |
| Number of Flutes | 6 |
| Coating | C6 |
| Profile | Spherical |
