Product Specifications
| Manufacturer Part Number | 825402-C6 |
| Cutter Diameter (Decimal Inch) | 0.109" |
| Cutter Diameter (Inch) | 7/64" |
| Neck Diameter (Decimal Inch) | 0.108" |
| Length of Cut (Decimal Inch) | 0.164" |
| Overall Reach (Decimal Inch) | 0.570" |
| Overall Length (Decimal Inch) | 2.500" |
| Overall Length (Inch) | 2-1/2" |
| Number of Flute | 5 |
| LOC Multiple | (1.5x) |
| Reach Multiple | (5x) |
| Shank Diameter (Decimal Inch) | 0.250" |
| Shank Diameter (Inch) | 1/4" |
| Metric | No |
| Coating | C6 |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
7/64"
Mill Diameter (Decimal Inch):
0.1090"
Mill Diameter (mm):
2.77mm
Number of Flutes:
5
Length of Cut (Inch):
5/32"
Length of Cut (Decimal Inch):
0.1640"
Length of Cut (mm):
4.17mm
Finish/Coating:
C6
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Shank Diameter (mm):
63.35mm
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Overall Length (mm):
63.50mm
Overall Reach (Inch):
9/16"
Overall Reach (Decimal):
0.5700"
Overall Reach (mm):
14.48mm
Interval quantity:
1
