Product Specifications
| Minor Diameter (Decimal Inch) | 0.2780" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| End To Center (Decimal Inch) | 0.2530" |
| Min Opening Width (Decimal Inch) | 0.2880" |
| End Length (Decimal Inch) | 0.0600" |
| Chamfer Length (Decimal Inch) | 0.0650" |
| Radius (Decimal Inch) | 0.0080" |
| Angle Per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 4 |
| Max Opening Width (Decimal Inch) | 0.3850" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Metric | No |
| Coating | AlTiN |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
Harvey Tool
Nominal Plate Thickness:
0.3750"
Max Opening Width:
0.3850"
Minor Diameter:
0.2780"
Shank Diameter (Decimal Inch):
0.3750"
Finish/Coating:
AlTiN
Material:
Solid Carbide
Ships:
From Partner Facility
interval quantity:
1
