Product Specifications
| Mill Diameter (Decimal Inch) | 0.1250" |
| Mill Diameter (Inch) | 1/8" |
| Neck Diameter (Decimal Inch) | 0.0620" |
| Neck Diameter (Inch) | 1/16" |
| Cutter Width (Decimal Inch) | 0.0930" |
| Cutter Width (Inch) | 3/32" |
| Neck Length (Decimal Inch) | 0.1870" |
| Neck Length (Inch) | 3/16" |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall Length (Inch) | 1-1/2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0220" |
| Corner Radius (Decimal Inch) | 0.0100" |
| Number of Flutes | 6 |
| Reach Multiple | (1.5x) |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Coating | Uncoated |
| Top Corner Radius | 0.01 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Milling Diameter (Inch):
1/8"
Milling Diameter (Decimal Inch):
0.1250"
Cutting Width (Inch):
3/32"
Cutting Width (Decimal Inch):
0.0930"
Corner Radius:
0.0100"
Neck Length (Inch):
3/16"
Neck Length (Decimal Inch):
0.1870"
Material:
Solid Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Tooth Configuration:
Straight
Ships:
From Partner Facility
