Product Specifications
Reamer Diameter (Inch) | 1/8" |
Reamer Diameter (Decimal Inch) | 0.1250" |
Neck Diameter (Decimal Inch) | 0.1210" |
Overall Reach (Inch) | 1-1/2" |
Overall Reach (Decimal Inch) | 1.5000" |
Overall Length (Inch) | 3" |
Overall Length (Decimal Inch) | 3.0000" |
Chamfer Length (Decimal Inch) | 0.0113" |
Angle per Side | 45 Degree |
Included Angle | 90 Degree |
Number of Flutes | 4 |
LOC Multiple | 7x |
Reach Multiple | 12x |
Margin Length (Inch) | 3/4" |
Margin Length | 0.7500" |
Shank Diameter (Inch) | 3/16" |
Shank Diameter (Decimal Inch) | 0.1875" |
Metric (Yes/No) | No |
Center Cutting (Yes/No) | No |
Chip Breaker (Yes/No) | No |
Finish/Coating | Uncoated |
Double Ended (Yes/No) | No |
Weldon Flat (Yes/No) | No |
Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Size (Inch):
1/8"
Size (Decimal Inch):
0.1250"
Material:
Carbide
Overall Reach (Inch):
1-1/2"
Overall Reach (Decimal Inch):
1.5000"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Flute Style:
Spiral
Number of Flutes:
4
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Ships:
From Partner Facility
IsDiscontinued:
