The Kurt DX8HR reverse vise is our newest addition to the automated DX vise series. The DX8HR shares many of the same great features of Kurt’s DX8 CrossOver vise with the addition of hydraulic actuation—allowing the vise to open and close using a Kurt pump system. Kurt pumps can make our hydraulic vise models actuate manually with a lever or foot-switch or operate within a fully automated robotic workflow as part of an automated machining cell.
Features a cast-on stationary jaw for less deflection—and a more stable vise body when clamping, 8-inch wide jaws with a 10-inch opening and our proprietary AngLock spherical segment creates all-directional alignment and reduces jaw lift for improved performance. Kurt hydraulic models come with single and double acting actuation that only requires switching out a brass fitting with the supplied hydraulic fitting.
The Kurt hydraulic unit has 1/4″ stroke.
Features Kurt’s Lifetime Ironclad Warranty.
For mounting information, please check out our mounting page or sine keys page.
Manufacturer Part Number | DX8HR |
Product Type | Hydraulic Reverse Vise |
