Features:
- Swiss IQ bar
- Round standard shank toolholder without side stopper
- Great for general horizontal and front-loading gang types
- For VNBR, VNBTR, VNGR, VNFGR, VNTR style inserts
Product Specifications
| EDP Number | THC07443 |
| Connection Diameter (Decimal Inch) | 0.7874" |
| Connection Diameter (mm) | 20.00mm |
| Shank Height (Decimal Inch) | 0.7087" |
| Shank Height (mm) | 18.00mm |
| Application | Micro Boring | Micro Internal Face Grooving | Micro Internal Grooving | Micro Internal Threading |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Series:
SWIQ;Shank Diameter (Decimal Inch)=0.7874"""
Shank Diameter (mm):
20.00mm
