- Flat bottom/counterboring
- Pilot point geometry and double margin for improved hole accuracy
- Reduced burr formation with large helix angle and corner chamfer
- Excellent chip evacuation with large groove and cutting edge angle for chip thinning
Product Specifications
| EDP Number | TLC10280 |
| Cutting Diameter (Decimal Inch) | 0.9055" |
| Cutting Diameter (mm) | 23.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.9055" |
| Cutting Diameter Minimum (mm) | 23.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.9055" |
| Cutting Diameter Maximum (mm) | 23.00mm |
| Application | Drilling |
| Chipbreaker | FTP |
| Coating Process | PVD |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Diameter (Decimal Inch):
0.9055"
Diameter (mm):
23.00mm
Material:
Carbide;Manufacturer's Grade=PR1535"
Series:
DRA
