Kyocera Precision Tools TSP00760 | SPCN63EETR1 TN100M 3/4" Circle Diameter x 3/16" Thickness Uncoated Cermet Milling Insert

$25.68
Brand:
Kyocera Precision Tools
Insert Size:
63
Material:
Cermet;Finish/Coating=Uncoated
Inscribed Circle (Decimal Inch):
0.7500"
Inscribed Circle (mm):
19.05mm
Thickness (Decimal Inch):
0.1900"
Thickness (mm):
4.76mm
SKU:
23250099
Weight:
0.09 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
  • Insert for milling
  • Chamfered edge with 1 cutting edge
  • Tough cermet with improved oxidation resistance and thermal shock resistance
  • Application: Turning of steel at high speed

Product Specifications
EDP NumberTSP00760
Insert Included Angle (Degree)90 Degree
Inscribed Circle (Inch)3/4"
[IC] Inscribed Circle (mm)19.05mm
[S] Thickness (Inch)3/16"
[S] Thickness (mm)4.76mm
ApplicationChamfering | Facing | Shouldering
ChipbreakerEETR1
Coating ProcessUncoated
