Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.6050" |
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Shank Diameter (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.5000" |
| Centerline Offset (Decimal Inch) | 0.3540" |
| Indexable Nomenclature | A08K STFCR 2 |
| Insert Style | TCMT 21.51 |
| Micro 100 Insert Part | 50-1300 |
| Overall Length (Decimal Inch) | 4.90" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Toolholder Style:
A08K STFCR 2
Minimum Bore Diameter (Decimal Inch):
0.6050"
Hand of Holder:
Right Hand
Overall Length (Decimal Inch):
4.90"
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Through Coolant:
Yes
Insert Compatibility:
TCMT 21.51
Ships:
From Partner Facility
