Product Specifications
Min Bore Diameter (Decimal Inch) | 0.1600" |
Hand Direction | Right Hand |
Finish/Coating | AlTiN |
Max Bore Depth (Decimal Inch) | 0.600" |
Projection (Decimal Inch) | 0.0400" |
Shank Diameter (Inch) | 3/16" |
Shank Diameter (Decimal Inch) | 0.1875" |
Centerline Offset (Decimal Inch) | 0.0663" |
Radius (Decimal Inch) | 0.0060" |
Face Dimension (Decimal Inch) | 0.094" |
Neck Diameter (Decimal Inch) | 0.1200" |
Overall Length (Inch) | 2" |
Overall Length (Decimal Inch) | 2.00" |
Split Length (Inch) | 9/64" |
Split Length (Decimal Inch) | 0.140" |
Tooth Width (Inch) | 1/8" |
Tooth Width (Decimal Inch) | 0.1250" |
![](https://cdn11.bigcommerce.com/s-mzpq4daxph/stencil/88df2040-d9f0-0136-9790-2bda68bb9491/e/2b057ed0-fa56-0136-27b1-73632bbf69c4/img/warning-icon_new.png)
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
![](https://cdn11.bigcommerce.com/s-mzpq4daxph/product_images/uploaded_images/warning-icon-new.png)
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Bore Diameter (Decimal Inch):
0.1600"
Maximum Bore Depth (Decimal Inch):
0.600"
Material:
Carbide
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.00"
Finish/Coating:
AlTiN
Ships:
From Partner Facility
IsDiscontinued:
