Product Specifications
| Finish/Coating | Uncoated |
| Angle per Side | 40 |
| Included Angle | 80 Degree |
| Brazed Insert Length (Inch) | 1/2" |
| Brazed Insert Length (Decimal Inch) | 0.500" |
| Brazed Insert Width (Inch) | 7/16" |
| Brazed Insert Width (Decimal Inch) | 0.438" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.00" |
| Shank Height (Inch) | 7/16" |
| Shank Height (Decimal Inch) | 0.4375" |
| Shank Width (Inch) | 7/16" |
| Shank Width (Decimal Inch) | 0.4375" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
D
Type:
Turning
Shank Width/Diameter (Inch):
7/16"
Shank Width/Diameter (Decimal Inch):
0.4375"
Shank Height (Inch):
7/16"
Shank Height (Decimal Inch):
0.4375"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.00"
Width (Decimal Inch):
0.4375"
Ships:
From Partner Facility
IsDiscontinued:
