Product Specifications
| Drill Diameter (Inch) | 5/64" |
| Drill Diameter (Decimal Inch) | 0.0781" |
| Coating | Uncoated |
| Flute Length (Inch) | 1/2" |
| Flute Length (Decimal Inch) | 0.500" |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Angle per Side | 30 Degree |
| Included Angle | 60 Degree |
| Drill Length (Inch) | 5/64" |
| Drill Length (Decimal Inch) | 0.078" |
| Overall Length (Inch) | 1-7/8" |
| Overall Length (Decimal Inch) | 1.88" |
| Point Angle | 118 Degree |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Drill Point Diameter (Inch):
5/64"
Drill Point Diameter (Decimal Inch):
0.0781"
Body Diameter (Inch):
3/16"
Body Diameter (Decimal Inch):
0.1875"
Included Angle:
60 Degree
Material:
Carbide
Finish/Coating:
Uncoated
End Type:
Single
Overall Length (Inch):
1-7/8"
Overall Length (Decimal Inch):
1.88"
Ships:
From Partner Facility
IsDiscontinued:
