Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.0850" |
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Max Bore Depth (Inch) | 1/2" |
| Max Bore Depth (Decimal Inch) | 0.500" |
| Projection (Decimal Inch) | 0.0050" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Centerline Offset (Decimal Inch) | 0.0450" |
| Face Dimension (Inch) | 1/16" |
| Face Dimension (Decimal Inch) | 0.063" |
| Neck Diameter (Decimal Inch) | 0.0800" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.50" |
| Split Length (Decimal Inch) | 0.180" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Bore Diameter (Decimal Inch):
0.0850"
Maximum Bore Depth (Inch):
1/2"
Maximum Bore Depth (Decimal Inch):
0.500"
Material:
Carbide
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.50"
Finish/Coating:
Uncoated
Ships:
From Partner Facility
IsDiscontinued:
