Product Specifications
| Hand Direction | Left Hand |
| Finish/Coating | Uncoated |
| Max Bore Depth (Decimal Inch) | 0.240" |
| Projection (Decimal Inch) | 0.2400" |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.00" |
| Shank Height (Inch) | 3/4" |
| Shank Height (Decimal Inch) | 0.7500" |
| Shank Width (Inch) | 3/4" |
| Shank Width (Decimal Inch) | 0.7500" |
| Tooth Width (Decimal Inch) | 0.0800" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
LC
Type:
Turning
Cutting Direction:
Left Hand
Shank Width/Diameter (Inch):
3/4"
Shank Width/Diameter (Decimal Inch):
0.7500"
Shank Height (Inch):
3/4"
Shank Height (Decimal Inch):
0.7500"
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.00"
Width (Decimal Inch):
0.080"
Finish/Coating:
Uncoated
Ships:
From Partner Facility
IsDiscontinued:
