Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.3700" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Inch) | 3/4" |
| Max Bore Depth (Decimal Inch) | 0.750" |
| Projection (Decimal Inch) | 0.1000" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Decimal Inch) | 0.1825" |
| Length from Holder (Decimal Inch) | 0.853" |
| Neck Diameter (Decimal Inch) | 0.2700" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.00" |
| Tooth Width (Decimal Inch) | 0.0390" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Projection (Decimal Inch):
0.1000"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.00"
Finish/Coating:
AlTiN
Width (Decimal Inch):
0.039"
Minimum Bore Diameter (Decimal Inch):
0.3700"
Maximum Bore Depth (Decimal Inch):
0.750"
Grooving Tool Type:
Retaining Ring
Ships:
From Partner Facility
IsDiscontinued:
