Product Specifications
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Max Bore Depth (Decimal Inch) | 0.240" |
| Projection (Decimal Inch) | 0.2400" |
| Overall Length (Inch) | 6" |
| Overall Length (Decimal Inch) | 6.00" |
| Shank Height (Inch) | 3/8" |
| Shank Height (Decimal Inch) | 0.3750" |
| Shank Width (Inch) | 3/8" |
| Shank Width (Decimal Inch) | 0.3750" |
| Tooth Width (Decimal Inch) | 0.0800" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
RC
Type:
Turning
Cutting Direction:
Right Hand
Shank Width/Diameter (Inch):
3/8"
Shank Width/Diameter (Decimal Inch):
0.3750"
Shank Height (Inch):
3/8"
Shank Height (Decimal Inch):
0.3750"
Overall Length (Inch):
6"
Overall Length (Decimal Inch):
6.00"
Minimum Bore Diameter (Decimal Inch):
0.0800"
Maximum Bore Depth (Decimal Inch):
0.240"
Finish/Coating:
Uncoated
Width (Decimal Inch):
0.0800"
Ships:
From Partner Facility
IsDiscontinued:
