Product Specifications
| Cutter Diameter (Decimal Inch) | 0.3600" |
| Coating | AlTiN |
| Flutes | 4 |
| Length of Cut (Decimal Inch) | 0.085" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Flat Width (Decimal Inch) | 0.002" |
| Neck Diameter (Decimal Inch) | 0.2100" |
| Neck Length (Inch) | 1" |
| Neck Length (Decimal Inch) | 1.000" |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.00" |
| Thread Size | 12-32 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Threads Per Inch:
12
Maximum Threads Per Inch:
32
Thread Type:
Internal/External
Material:
Carbide
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Number of Flutes:
4
Cutter Diameter (Decimal Inch):
0.3600"
Neck Diameter (Decimal Inch):
0.2100"
Neck Length (Inch):
1"
Neck Length (Decimal Inch):
1.000"
Finish/Coating:
AlTiN
Ships:
From Partner Facility
