Product Specifications
| # Manufacturer Number | 0573023 |
| Diameter (mm) | 7.10mm |
| Shank Size (mm) | 8.00mm |
| Flute Length (mm) | 34.00mm |
| Overall Length (mm) | 78.00mm |
| Drill Point Angle | 135 Degree |
| Number of Flute | 2 |
| Material | Powdered Metal HSCO Steel |
| Finish / Coating | Tin+TiCN |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Flute Type:
Conventional Spiral
Drill Bit Size (Inch):
2/7";Drill Bit Size (Decimal Inch)=0.2795""
Drill Bit Size (mm):
7.10mm
Drill Point Angle:
135 Degree
Overall Length (Inch):
3";Overall Length (Decimal Inch)=3.0709""
Overall Length (mm):
78.00mm
Cutting Direction:
Right
Material:
Powdered Metal HSCO Steel
Finish/Coating:
Tin+TiCN
Shank Type:
Endmill Type Shank
Coolant Through:
No
